Use the Fluorescent Retrofit Guide tables below to help choose the right retrofit kit to convert your inefficient T12 fluorescent fixture to efficient T8 or T5 lamps. If you have questions, please don't hesitate to contact us.
Helpful Information For Fluorescent Retrofits:
T12 Lamps = Old Technology Inefficient
T8 Lamps = Newer Technology, Efficient, Flexible Energy Saving Options
T5 Lamps = Newest Technology, Efficient and High Output
Specular = 86% Reflectivity | White = 91% Reflectivity | MIRO = 95% Reflectivity
Prismatic = Solid Lens that diffuses light evenly
Parabolic = Open Celled Lens that directs light without glare
2X2, 2X4 Troffer Fluorescent Retrofit - 2 Lamp |
|||
| Converts: 2x2 or 2x4 To: T8 2 Lamp | 2x2 or 2x4 2 Lamp Prismatic - Standard Body Width T8 2' - White | MIRO | Specular T8 4' - White | MIRO | Specular T5 - Available please contact | 2x2 or 2x4 2 Lamp Parabolic - 6 or 12 Cell T8 2' - White | MIRO | Specular T8 4' - White | MIRO | Specular T5 - Available please contact | 2x4 2 Lamp Parabolic -18 Cell 4' - White | MIRO | Specular T5 - Available please contact |
2x2 or 2x4 Fluorescent Retrofit - 3 Lamp |
|||
| Converts: 2x2 or 2x4 To: T8 or T5 3 Lamp | 2x4 3 Lamp Prismatic - Narrow Body Width T8/T5 - Please contact for Purchase | 2x4 3 Lamp Prismatic - Standard Body Width T8 2' - White | MIRO | Specular T8 4' - White | MIRO | Specular T5 - Available please contact | 2x2 or 2x4 3 Lamp Parabolic - 9 or 18 CellT8 2' - White | MIRO | SpecularT8 4' - Available please contactT5 - Available please contact |
2x4 Fluorescent Retrofit - 4 Lamp |
|||
| Converts: 2x4 To: T8 or T5 4 Lamp | 2x4 4 Lamp Prismatic T8 2' - White | MIRO | Specular T8 4' - White | MIRO | Specular T5 - Available please contact | ||
1 x 4 Fluorescent Retrofit - 1 or 2 Lamp |
|||
| Coverts: T12 1x4 To: T8 or T5 1 or 2 Lamp | 1x4 1 or 2 Lamp Prismatic - Narrow Body Width1 Lamp T8 White | MIRO | Specular2 Lamp T8 White | MIRO | SpecularT5 - Available please contact | 1x4 1 Lamp Prismatic - Wide Body Width1 Lamp T8 White | MIRO | Specular2 Lamp T8 White | MIRO | Specular 1 Lamp T5 - MIRO2 Lamp T5 - MIRO | |
2x4 Fluorescent Retrofit - 2 or 3 Lamp Pre-Assembled |
|||
| Converts: 2x4 To: T8 or T5 2 or 3 Lamp Pre Assembled | 2x4 Snapkit - 2 or 3 LampT8/T5 - Please contact for Purchase | ||
4 to 8 Foot Fluorescent Retrofit - Added Reflector |
|||||
| Converts: 4' or 8' To: T8 or T5 with 4' lamps Adds: Reflector | Strip Kit - High ProfileT8 1 or 2 Lamp (4') White | MIRO | SpecularT8 2 or 4 Lamp (8') White | MIRO | SpecularT5 2 or 4 Lamp (8') MIRO | Strip Kit - Low ProfileT8 1 or 2 Lamp (4') White | MIRO | SpecularT8 2 or 4 Lamp (8') White | MIRO | Specular T5 2 or 4 Lamp (8') MIRO | Strip Kit - Shallow ProfileT8 1 or 2 Lamp (4') White | MIRO | SpecularT8 2 or 4 Lamp (8') White | MIRO | SpecularT5 Available please contact | Strip Kit - Medium ProfileT8 3 Lamp (4') White | MIRO | SpecularT8 6 Lamp (8') White | MIRO | SpecularT5 Available please contact | Strip Kit - High Profile - 4 Lamp (4') - 8 Lamp (8')T8/T5 - Please contact for Purchase |
4 to 8 Foot Fluorescent Retrofit - Wrap Lens |
|||||
| Coverts: 4' or 8' To: T8 or T5 with 4' lamps Adds Wrap Lens | Strip Kit - Strip To WrapT8 1 or 2 Lamp (4') White | MIRO | SpecularT8 2 or 4 Lamp (8') White | MIRO | SpecularT5 Available please contact | ||||
4 - 8 Foot Fluorescent Retrofit - No Reflector |
|||||
| Coverts: 4' or 8' Strip To: T8 or T5 with 4' lamps No Reflector | Strip Kit - One Piece Ballast Pan - 4.25" or 5" channel - No Brackets - Sockets Direct4' - 1 Lamp 4.25"4' - 2 Lamp 4.25"4' - 1 Lamp 5"4' - 2 Lamp 5"8' - 2 Lamp 4.25"8' - 4 Lamp 4.25" 8' - 2 Lamp 5" 8' - 4 Lamp 5" | Strip Kit - Ballast Pan 5" - Brackets 4.25" to 5" - Sockets to Bracket4' - 1 or 2 Lamp Adjustable (Most Popular Kit)4' - 1 Lamp 4.25"4' - 2 Lamp 4.25"4' - 1 Lamp 5"4' - 2 Lamp 5" 8' - 2 Lamp 4.25" 8' - 4 Lamp 4.25" 8' - 2 Lamp 5" 8' - 4 Lamp 5" | Strip Kit - One-Piece Chain Clip - Channel covers 4-5" -No Brackets -Sockets Direct4' - 1 Lamp 4' - 2 Lamp8' - 2 Lamp8' - 4 Lamp | ||
