SLG Lighting FFW DLC Premium Listed Wave Series LED Flat Flood Light Fixture Gen 1 Dimmable
SLG Lighting FFW DLC Premium Listed Wave Series LED Flat Flood Light Fixture Gen 1 Dimmable
-
Specsheet:
Specifications
Specifications
| Part Number# | FFW 510 WFL G1 5K |
|---|---|
| Type of Area: | Landscape & Flood, Pole / Street / Parking Lot, Sign & Billboards, Wall Mount & Building Exteriors |
| Color Temp: | 5000K - Daylight White |
| Lamp Life: | 200,000 Hours |
| Lumen Output: | 10,046 - 55,860 |
| Ballast Start Type: | Instant Start |
| Certifications | 10 Year Warranty, Dimmable, DLC Premium, FCC Compliant, IP65 / IP66 / IP67, ROHS, UL Listed |
| CRI: | 70 |
| Dimensions: | 14.84" - 16" x 5.76" - 6.3" x 19.17" - 27.35" |
| Width: | 5.76" - 6.3" |
| Length: | 14.84" - 16" |
| Height: | 19.17" - 27.35" |
| Dimmable: | Yes |
| Product Warranty: | 10 Year |
| Minimum Start Temperature: | -40 Deg F |
| Voltage: | Multivolt 120V-277V |
| Weight Each: | 13.25 - 20.95 lbs |
| Manufacturer: | SLG Lighting |
| Technology: | LED - New Fixture |
Details
Details
ShineRetrofits Input:
This Flat Flood Light Wave Series Gen 1 offers a modern design and energy-saving solution for outdoor lighting. Select from Medium and Large sizes at 70W to 380W replacing 150W to 1000W Metal Halide fixtures and delivering 10,046 to 55,860 lumens. Housing is constructed of die-cast aluminum with advanced heatsink technology to withstand outdoor conditions with DLC Premium rating back-up by a 10-year limited warranty.
Features:
• Manufactured die-cast aluminum housing
• Low profile, compact design carries 3G vibration rating per ANSI C136.31.
• Suitable for use in -40°C to 45°C (-40°F to 113°F)
• Mounting options include Square and Round Pole Mount, Wall Mount, Trunnion Mount, and Adjustable Slipfitter Mount.
• Lumen packages ranging from 10,046 to 55,860 lumens
• 4000K, and 5000K CCT available; 70CRI
• Precision molded secondary NEMA 6H x 7V optics
• 10-year limited warranty. 1-year labor warranty. Comprehensive warranty terms can be located on www.slgus.com
• Standard 0-10V Dimming.
• DesignLights Consortium® (DLC) Premium 5.1 qualified product.
Model Numbers:
FFW 100 WFL G1
FFW 150 WFL G1
FFW 210 WFL G1
FFW 280 WFL G1
FFW 340 WFL G1
FFW 430 WFL G1
FFW 510 WFL G1
