ShineRetrofits Input:
RAB Lighting’s BULLET line of floodlights offer you many choices. Available in 3000K, 4000K and 5000K color temperatures and with choices of housing colors: black, white, bronze, green/verde. These units make great efficient, economical replacements to 75W BR30/halogen/wide flood. These mount on the RAB Mighty Post or a junction box in an up or downright up or downlight orientation. The microprismatic diffusion lens assures smooth and even light distribution. 100,000-hour LED Lifespan makes this an economical and low maintenance part of your design.

BULLET12 complies with 2013 California Title 24 building and electrical codes as a residential outdoor lighting fixture with no additional hardware required and as a commercial outdoor non-pole-mounted fixture = 30 Watts when used with a photosensor control. Select catalog number PCS900 to order a photosensor.

Listings:
• UL Listing: Suitable for wet locations
• IESNA LM-79 & LM-80 Testing: RAB LED luminaries have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80, and have  received the Department of Energy "Lighting Facts" label.
• California Title 24: See compliance statement above for use with PCS900 photosensor.

LED Characteristics:
• Mulii-chip, high-output, long-life LEDs
• Lifespan: 100,000•Hour LED lifespan based on IES LM-80 results and TM-21 calculation
• Color Stability: LED color temperature is warrantied to shift no more than 200K in CCT over a 5 year period.
• Color Uniformity: RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2011.
• 3000K (Warm), 83 CRI, Lumens: 800, Efficacy: 61 LPW, Efficiency: 91
• 4000K (Neutral), 84 CRI, Lumens: 832, Efficacy: 64 LPW, Efficiency: 92

• 5000K (Neutral), 84 CRI, Lumens: 957, Efficacy: 74 LPW, Efficiency: 92

Electrical:
• Driver: Innovative integrated driver technology with 120V TRIAC and ELV dimming
• Type: Constant Current
• Driver: 120V: 0.10A, Input Watts: 13W

Construction:
• Thermal Management: Superior heat sinking with external Air-Flow fins
• Housing: Die-cast aluminum housing, lens frame and mounting plate
• Reflector: Semi-specular, vacuum-metalized polycarbonate
• Lens: Microprismatic diffusion lens for smooth and even light distribution
• Mounting: Heavy-duty mounting arm with "O" ring seal and stainless steel screws
• Gaskets: High-temperature silicone gaskets
• Finish: Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color, and contain no VOC or toxic heavy metals.
• Green Technology: Mercury and UV free, and RoHS compliant. Polyester powder coat finish formulated without the use of VOC or toxic heavy metals.

Model Numbers:
BULLET12A, BULLET12B, BULLET12NA, BULLET12NB, BULLET12NW, BULLET12VG, BULLET12W, BULLET12YA, BULLET12YB, BULLET12YVG
