Nicor Lighting DLR56 Series Energy Star Rated 5/6-Inch LED Recessed Downlight Retrofit Dimmable
Nicor Lighting DLR56 Series Energy Star Rated 5/6-Inch LED Recessed Downlight Retrofit Dimmable
Specifications
Specifications
| Part Number# | DLR56 |
|---|---|
| Type of Area: | Apartment Buildings, Home & Architectural, Office & Small Retail, Schools, Hotels, Hospitals, Commercial Offices, Education, Hospitality, Retail, Banking |
| Lamp Life: | 50,000+ Hours |
| Lumen Output: | 918 - 1,248 |
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, Dimmable, Energy Star, ETL Listed, FCC Compliant, LM79 / LM80, NEC, NFPA, ROHS, Title 24 Compliant |
| CRI: | 93 |
| Dimensions: | 7.4" |
| Length: | 7.4" x 3.5" |
| Height: | 3.5" |
| Dimmable: | Yes |
| Product Warranty: | 5 Year |
| Minimum Start Temperature: | -4 Deg F |
| Voltage: | 120V |
| Manufacturer: | Nicor |
| Technology: | LED - New Fixture |
Details
Details
ShineRetrofits Input:
NICOR's DLRv6 recessed LED downlight is an excellent choice for new construction applications using standard housings, the patented new construction frame, or as a retrofit into most 5/6-inch housings. This updated version meets the latest certification standards, boasting over 80 lumens per watt (LPW), a 90+ CRI, and an R9 greater than 50, ensuring superior lighting quality. The DLR Single CCT model is available in 3000K, while the DLR Select model offers enhanced flexibility with a micro-switch on the driver cap, allowing users to adjust the CCT to 2700K, 3000K, 3500K, 4000K, or 5000K. This adaptability makes it suitable for a variety of lighting preferences and applications.
Features:
• Single CCT LED used for 3000K standard model.
• Selectable models use a dual emitter array that enables CCT selection of 2700, 3000, 3500, 4000, or 5000K
• Utilizes high performing LEDs with 90+ CRI and an R9 > 50
• Polystyrene diffuser creates uniform distribution without sacrificing lumen output
• Dimmable to 5% with compatible leading edge (TRIAC) or trailing edge (ELV) dimmers
• Compatible with most 5/6-Inch recessed housings
• Quick and easy installation with an IDEAL luminaire connector and torsion spring or friction fit mounting system
• Ships with Edison base socket string (GU24 socket string available)
• 5-year limited system warranty
• Compliant with NFPA® 70, NEC® Section 410.16 (A)(3) and 410.16 (C)(5) for closet use
• RoHS Compliant
• Meets FCC Part 15, Subpart B, Class B standards for conducted and radiated emissions
• ICES-005 Compliant
• LED lumen maintenance: L70(9k)>54,000 hrs for DLR56609
• LED lumen maintenance: L70(12k)>72,000 hrs for DLR5612
