MaxLite EVMax+ LW101 BAA Compliant Level 2 Charger Modular EVSE
MaxLite EVMax+ LW101 BAA Compliant Level 2 Charger Modular EVSE
Specifications
Specifications
| Part Number# | LW101 |
|---|---|
| Type of Area: | Gas Station & Convenience Store, Large Retail & Open Areas, Parking Garage, Retail |
| Ballast Start Type: | Instant Start |
| Certifications | FCC Compliant, Made In America Compliant, UL Listed |
| Dimmable: | No |
| Manufacturer: | Maxlite |
Details
Details
ShineRetrofits Input:
MaxLite's EVMax+ BAA-compliant Level 2 EV charger is designed for fast deployment and reliable performance. It offers adjustable charging from 12A to 48A or 80A, delivering up to 11.5kW at 240V. Featuring the EZ-Swap Faceplate™, built-in Wi-Fi or cellular connectivity, and support for local load management, it ensures easy operation and maintenance. Suitable for indoor or outdoor use, the EVMax+ is built for durability, flexibility, and long-term EV charging needs.
Electrical:
• Safety Rated to 48/80Amps Max. Adjustable Down to 12Amps.
• Rated Voltage 208 to 240 Volts AC @ 60Hz
• Charging Power @ 240V is 11.5kW Adjustable Down to 2.9kW
• Hardwire Lug Connection Through Back or Bottom of Unit
• 1% Energy Meter Accuracy
Connector and Cable:
• J1772 Type 1
• High-quality Flexible Cable
• 18ft or 25ft Options Available
Networking and Communications:
• Built-in Wi-Fi on EVMP1-48W & EVMP1-48C Units (2.4GHz 802.11 b/g/n)
• Built-in Cellular on EVMP1-48C Units (LTE CAT.M1)
• Connect Up to 9 EVMP1-48W Units to 1 EVMP1-48C
• Over-the-air firmware updates are automatic when connected to Lynkwell's network. Requires one EVMP1-48C with cellular communication be installed
• Local Load Management
• OCPP 1.6. OCPP 2.0 in Development (2024)
Environment:
• Indoor & Outdoor Rated, NEMA 3R
• Operating Temperature: -22°F To 122°F (-30°C To 50°C)
• Storage Temperature: -22°F To 176°F (-30°C To 80°C)
• Humidity: 95% RH Non-Condensing
Display and Indicators:
• 2.7in (W) X 1.5in (H)
• Resolution 128 Pixel X 64 Pixel
• LEDs Provide Highly Visible EVSE Status Indicators
Device Mounting:
• Wall or Pedestal
• Bracket Dimensions 3.4in (W) X 8.75in (H) X 0.67in (D)
• Device Dimension 6.1in (W) X 14.11in (H) X 4.53in (D)
