LSI IHB Series Industrial LED Linear High Bay offers smooth and uniform light with a high-efficiency lens that eliminates glare. Constructed from die-formed thick gauge steel and aluminum, it features a quick wire access panel designed to meet ESFR fire suppression system requirements. Available without a lens for maximum output or with a scratch-resistant high-impact lens, it provides a minimum CRI of 82 and dimming from 1% to 100%. The fixture is UL-listed, suitable for damp locations, and comes with a 5-year limited warranty.

Features:
• Smooth & uniform light
• Tool-free high transmission lens option
• High-efficiency lens eliminates glare and improves visual comfort
• Traditional fluorescent appearance
• Slim 7 1/4″ form factor

Construction:
• Rigid housing is die-formed thick gauge steel and aluminum
• All metal parts are painted after fabrication following treatment with
phosphate rust inhibitor. Finish coating of housing reflecting surfaces is with high-reflectance white (minimum 92%) polyester powder.
• Lightweight heatsinks are designed to perform in ambient temperatures up to 55C
• Quick wire access panel allows for easy power connections
• 7 1/4” width meets ESFR fire suppression system requirements

Optical System:
• Available without lens for maximum lumen output or with high impact, scratch-resistant lens (91% efficiency)
• Minimum CRI of 82

Electrical:
• Standard Universal Voltage (120-277 VAC) Input 50/60Hz or optional High Voltage (347-480 VAC)
• L70 Calculated Life: 200,000+ hours
• Driver is constant current, Class 2, 120-277 Vac, 50/60Hz
• High Efficiency Driver: minimum 85%
• 0-10V dimming (1% - 100%) standard
• Optional 120v-277v integral emergency battery pack is available to meet critical life safety lighting requirements. The 90-minute batteries provide constant power to the LED system, ensuring code compliance. A test switch/indicator button is installed on the housing for ease of
maintenance.
• Emergency Backup Drive has 5W input, 10W output

Controls:
• Controls Options include:
- Simple Sensor PIR end mount motion sensor available (OMSx).

Installation:
• Suitable for suspension by chain, cable, or single (pendant) monopoint with minimum 6” from ceiling

Warranty:
• LSI luminaires carry a 5-year limited warranty.

Listings:
• Listed to UL 1598 and UL 8750.
• Meets Buy American Act requirements.
• Title 24 Compliant; see local ordinance for qualification information.
• Suitable for damp locations.
• DesignLights Consortium® (DLC) Premium qualified product. Not all versions of this product may be DLC Premium qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
• IK08 rated luminaire per IEC 66262 mechanical impact code
