LSI Industries AHB Series Advantage LED Linear High Bay Light Fixture Dimmable
LSI Industries AHB Series Advantage LED Linear High Bay Light Fixture Dimmable
-
Specsheet:
Specifications
Specifications
| Part Number# | AHB |
|---|---|
| Type of Area: | Gym & Sports, Industrial & Warehouse, Factory / Industrial |
| Lamp Life: | 50,000+ Hours |
| Lumen Output: | 18,000 - 60,000 |
| Wattage: | 400 Watt |
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, CUL Listed, Dimmable, DLC Premium, ROHS, UL Listed, Title 24 Compliant |
| CRI: | >80 |
| Width: | 11.88" - 15.13" |
| Length: | 24.88" - 47.25" |
| Dimmable: | Yes |
| Product Warranty: | 5 year limited warranty |
| Minimum Start Temperature: | -40 Deg F |
| Voltage: | Multivolt 120V-277V |
| Weight Each: | 7.2 - 9 lbs |
| Manufacturer: | LSI Lighting |
| Technology: | LED - New Fixture |
Details
Details
ShineRetrofits Input:
LSI AHB Series Advantage LED Linear High Bay Light Fixture is a versatile and high-performing lighting solution. Available in both 4000K and 5000K, it comes in 2ft and 4ft lengths with various lumen packages. It features standard mounting with included V hooks and offers optional occupancy sensors and daylight harvesting sensors. Constructed from high-quality steel with a frosted acrylic resin lens, it is UL-listed, damp location suitable, and California Title 24 compliant.
Features & Specifications:
• Available in 4000K or 5000K
• Available in 2ft (18L, 24L, 30L) and 4ft (48L, 60L)
• Standard mounting with included V hooks
• Optional external or integral passive infrared occupancy sensor available
• Optional integral bluetooth programmable daylight harvesting sensor available
• Option pendant mount options available
• High-quality steel construction with paint after-fabrication finish
• Acrylic resin lens
• Frosted lens design for maximum light output
• List for UL 1598 and UL 8750
• Suitable for damp locations
• State of California Title 24 compliant
• DLC-qualified product. Not all versions of this product may be DLC-qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
