Keystone KTEB-239HO-UV-PS-SL T5HO Electronic Ballast 2 Lite F39T5HO Program Start Electronic Ballast 9" case
Keystone KTEB-239HO-UV-PS-SL T5HO Electronic Ballast 2 Lite F39T5HO Program Start Electronic Ballast 9" case
Specifications
Specifications
| Part Number# | KTEB-239HO-UV-PS-SL |
|---|---|
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, CEE Listed, NEMA, UL Listed |
| Dimmable: | No |
| Product Warranty: | 5 Year |
| Voltage: | Multivolt 120V-277V |
| Weight Each: | 1.03 |
| Manufacturer: | Keystone Technologies |
Details
Details
ShineRetrofits Input:
Keystone KTEB-239HO-UV-PS-SL is a T5HO electronic ballast designed for 2-light F39T5HO fixtures, featuring a 9" case and program start method. Operating with an input voltage of 120-277V and a high power factor, this ballast is rated for a maximum case temperature of 194ºF (90ºC) and a minimum starting temperature of 0ºF (-18ºC). It meets FCC Part 18 (Class A) non-consumer limits, UL and cUL 935 listed, and includes transient protection per ANSI/IEEE C62.41 Cat. A, as well as lamp end-of-life protection. Suitable for Class P, Type 1 outdoor use, and both Type HL and Type CC applications, it comes with a 5-year warranty.
Product Features:
• Sound Rated: A
• Minimum Starting Temperature: 0ºF, -18ºC
• Maximum Case Temperature: 194ºF, 90ºC
• Meets FCC Part 18 (Class A) Non-Consumer Limits
• UL, cUL 935 Listed
• Transient Protection Meets ANSI/IEEE C62.41 Cat. A
• Lamp End-of-Life Protected
• Class P, Type 1 Outdoor
• Type HL, Type CC
Product Specifications:
• STARTING METHOD: Program Start
• LAMP CONNECTION: Series
• INPUT VOLTAGE: 120-277Vac ±10%
• INPUT FREQUENCY: 50/60 Hz
• POWER FACTOR: High
• WARRANTY: 5 Years
