Barron Lighting LPX-24-CP4 Power and Color Switchable 2x4 LED Backlit Flat Panel Dimmable
Barron Lighting LPX-24-CP4 Power and Color Switchable 2x4 LED Backlit Flat Panel Dimmable
Specifications
Specifications
| Part Number# | LPX-24-CP4 |
|---|---|
| Type of Area: | Office & Small Retail, Schools, Hospitals, Commercial Offices, Education, Hospitality, Retail |
| Color Temp: | Selectable CCT |
| Lamp Life: | 50,000+ Hours |
| Lumen Output: | 3,600 - 5,492 |
| Wattage: | 50 Watt |
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, CUL Listed, Dimmable, DLC Approved, UL Listed |
| CRI: | ≥80 |
| Dimensions: | 47.8" x 23.8" x 1.4" |
| Width: | 23.8" |
| Length: | 47.8" |
| Height: | 1.4" |
| Dimmable: | Yes |
| Product Warranty: | 5 Year |
| Minimum Start Temperature: | -4 Deg F |
| Voltage: | Multivolt 120V-277V |
| Manufacturer: | Barron |
| Technology: | LED - New Fixture |
| Fixture Length: | 4 Feet / 48 Inches |
Details
Details
ShineRetrofits Input:
Barron Lighting's LPX 2x4 LED-Backlit Flat Panel Dimmable fixture offers superior performance with an adjustable, energy-efficient, low-profile design. It provides flexibility by allowing users to adjust the color temperature (CCT) and wattage, ensuring optimal lighting for various applications. It is ideal for office spaces, schools, hospitals, and indoor locations requiring even illumination and low maintenance, compatible with most standard T-bar grid ceilings, and includes 0-10V dimming. Featuring PMMA optical lensing that resists yellowing over time, this series is DesignLights Consortium® (DLC) Qualified for energy rebates.
Construction:
• Cold rolled carbon steel enclosure in a white finish
• Aluminum frame with seamless corners
• Recessed design fits most standard T-bar grid ceilings, only 1.4” thickness
• Backlit design, LEDs sit at the back of the enclosure aimed directly at the diffuser to evenly illuminate the entire surface of the panel
• Sturdy frame prevents warping due to the slightly more elevated profile
Optics/LEDs:
• Switchable between four color temperatures: 3000K, 3500K, 4000K and 5000K CCT. Switch located outside driver box behind the unit
• For panels with non-switchable CCT see the LPX Series.
• CRI ≥80
• Efficacy up to 122 lumens per watt
• L70 > 50,000hrs
• UV-stabilized PMMA optical lenses over the LEDs that will not yellow over time
Electrical:
• Universal 120-277VAC, 50/60Hz
• Power Factor > 0.90
• 0-10V Dimming driver
• 2' x 4' configuration between 30W, 40W and 50W. Switch located outside driver box behind the unit
Testing & Compliance:
• cULus Listed for Damp Locations, IC rated for insulated ceilings
• IP20 Rated
• DesignLights Consortium® (DLC) Qualified
• Operating temperatures: -20°C to 40°C (-4°F to 40°C)
Installation:
• Unit simply lifts through grid ceiling and rests on T-bars
• Easy installation in new construction or retrofit
• Standard recessed mounting in most 1 'x 4', 2’ x 2’ or 2’ x 4’ grid ceilings
• Earthquake clips included
• Easily set wattage and CCT during installation using the adjustment switches located outside the driver box
Warranty:
• Five Year Warranty (Terms and Conditions Apply)
