Barron Lighting LED-90 Series 1-Watt Thermoplastic LED Emergency Lighting Unit with Fully Adjustable Head
Barron Lighting LED-90 Series 1-Watt Thermoplastic LED Emergency Lighting Unit with Fully Adjustable Head
Specifications
Specifications
| Part Number# | LED-90 |
|---|---|
| Type of Area: | Home & Architectural, Schools, Hotels, Hospitals, Retail |
| Lamp Life: | 100,000 Hours |
| Wattage: | 1 Watt |
| Ballast Start Type: | Instant Start |
| Certifications | 5 Year Warranty, UL Listed |
| Dimensions: | 10.5" x 3.5" x 3.3" |
| Width: | 3.5" |
| Length: | 10.5" |
| Height: | 3.3" |
| Dimmable: | No |
| Product Warranty: | 5 Year |
| Minimum Start Temperature: | 32 Deg F |
| Voltage: | Multivolt 120V-277V |
| Manufacturer: | Barron |
| Technology: | LED - New Fixture |
Details
Details
ShineRetrofits Input:
The Barron Lighting LED-90 Series is a 1.1-watt thermoplastic LED emergency lighting unit equipped with fully adjustable heads. Each head contains eight long-lasting, efficient, ultra-bright LEDs. Available in black or white finish, this unit is suitable for damp locations, providing reliable and versatile emergency lighting solutions.
Features:
• Each head contains eight long-lasting, efficient, ultrabright, white LEDs consuming 1.1W per head
• Rugged, injection-molded UL 94 5VA flame-retardant, high-temperature thermoplastic housing
• Remote capable - up to two 1.5W MLED remote heads
• UL Listed 90-minute emergency run time, 24-hour recharge time
• Suitable for Damp Locations
Specification:
• Illumination: Each head contains eight long-lasting, efficient, ultrabright, white LEDs consuming
1.1W per head
• Housing: Low-profile, streamlined, die-cast aluminum housing
• Input: 120/2777VAC Dual primary, 60Hz
• Battery: Maintenance-free NiCad battery
• Operating Temp: 0°C to 40°C (32°F to 104°F)
• Run Time: UL Listed 90-minute emergency run time, 24-hour recharge time
• Mounting: Ceiling or wall mount with universal J-box mounting pattern and rear keyhole slots, includes top and side conduit entry options
• Finishes: Black or White
• Options: G2 - Guardian Self-test/Self-diagnostics R - Remote Capable (6W)
• Certifications: UL 924 Listed for Damp Locations, meets or exceeds NEC requirements and NFPA 101
• Warranty: Any component that fails due to a manufacturing defect is guaranteed for five
years with a separate five-year prorated warranty on the battery. The warranty does not
cover physical damage, abuse, or instances of uncontrollable natural forces.
